Extended Terraform Tutorial for AWS Deployment

In this Extended Terraform Tutorial, we’ll guide you through the process of deploying scalable infrastructure on AWS using Terraform. This tutorial covers everything from setting up auto-scaling groups and load balancers to configuring networking essentials for high availability. Whether you’re a beginner or looking to refine your cloud infrastructure skills, this step-by-step guide will help you deploy a fully functional AWS environment with minimal manual intervention.

Step 1: Install Terraform on Debian 12

Run the following commands to install Terraform:

sudo apt update && sudo apt install -y gnupg software-properties-common curl
curl -fsSL https://apt.releases.hashicorp.com/gpg | sudo gpg --dearmor -o /usr/share/keyrings/hashicorp-archive-keyring.gpg
echo "deb [signed-by=/usr/share/keyrings/hashicorp-archive-keyring.gpg] https://apt.releases.hashicorp.com $(lsb_release -cs) main" | sudo tee /etc/apt/sources.list.d/hashicorp.list
sudo apt update && sudo apt install -y terraform

Verify installation:

terraform -v

Step 2: Configure AWS Credentials

Create an AWS IAM user with Programmatic Access and assign the AdministratorAccess policy.
Once you have the Access Key ID and Secret Access Key, run:

aws configure

Enter the following when prompted:

AWS Access Key ID → (Your Access Key ID)
AWS Secret Access Key → (Your Secret Key)
Default region → us-east-1 (or your preferred region)
Default output format → json

Verify AWS connectivity:

aws s3 ls

Step 3: Create the Terraform Project

Create the project directory and the necessary files:

mkdir terraform-aws-scaled && cd terraform-aws-scaled
touch main.tf variables.tf outputs.tf

Step 4: Write the Terraform Configuration Files

`main.tf` – Main Infrastructure Configuration

provider "aws" {
  region = var.aws_region
}

# VPC Creation
resource "aws_vpc" "main" {
  cidr_block = "10.0.0.0/16"
  enable_dns_support = true
  enable_dns_hostnames = true
}

# Subnet Creation
resource "aws_subnet" "subnet" {
  vpc_id     = aws_vpc.main.id
  cidr_block = "10.0.1.0/24"
  availability_zone = "us-east-1a"
  map_public_ip_on_launch = true
}

# Security Group
resource "aws_security_group" "sg" {
  name        = "terraform-sg"
  description = "Allow HTTP, SSH, and load balancer access"

  ingress {
    from_port   = 22
    to_port     = 22
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]
  }

  ingress {
    from_port   = 80
    to_port     = 80
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]
  }

  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }
}

# Launch Template for Auto Scaling
resource "aws_launch_template" "lt" {
  name_prefix   = "terraform-template"
  image_id      = var.ami_id
  instance_type = var.instance_type
  security_group_names = [aws_security_group.sg.name]
  key_name      = var.key_name
  user_data     = data.template_file.user_data.rendered
}

# Auto Scaling Group
resource "aws_autoscaling_group" "asg" {
  desired_capacity     = 2
  min_size             = 1
  max_size             = 3
  vpc_zone_identifier  = [aws_subnet.subnet.id]
  launch_template {
    id      = aws_launch_template.lt.id
    version = "$Latest"
  }

  health_check_type          = "EC2"
  health_check_grace_period = 300
  force_delete              = true
}

# Application Load Balancer
resource "aws_lb" "alb" {
  name               = "terraform-lb"
  internal           = false
  load_balancer_type = "application"
  security_groups   = [aws_security_group.sg.id]
  subnets            = [aws_subnet.subnet.id]
}

# Target Group
resource "aws_lb_target_group" "tg" {
  name     = "terraform-tg"
  port     = 80
  protocol = "HTTP"
  vpc_id   = aws_vpc.main.id
}

# Listener for Load Balancer
resource "aws_lb_listener" "listener" {
  load_balancer_arn = aws_lb.alb.arn
  port              = "80"
  protocol          = "HTTP"

  default_action {
    type             = "fixed-response"
    fixed_response {
      status_code = 200
      content_type = "text/plain"
      message_body = "OK"
    }
  }
}

# Attach Auto Scaling Group to Load Balancer Target Group
resource "aws_lb_target_group_attachment" "asg_attachment" {
  target_group_arn = aws_lb_target_group.tg.arn
  target_id        = aws_autoscaling_group.asg.id
  port             = 80
}

`variables.tf` – Variables for Customization

variable "aws_region" {
  default = "us-east-1"
}

variable "ami_id" {
  default = "ami-0c55b159cbfafe1f0"  # Update with your region's AMI
}

variable "instance_type" {
  default = "t3.micro"
}

variable "key_name" {
  default = "my-aws-key"  # Replace with your AWS Key Pair
}

`outputs.tf` – Display Useful Information

output "load_balancer_url" {
  value = aws_lb.alb.dns_name
}

output "autoscaling_group_name" {
  value = aws_autoscaling_group.asg.name
}

Step 5: Initialize Terraform

Initialize the Terraform project:

terraform init

Step 6: Preview the Changes (Optional)

To see what will be created:

terraform plan

Step 7: Deploy the Infrastructure

Apply the configuration to create the resources:

terraform apply -auto-approve

Step 8: Access the Deployed Infrastructure

Once the deployment is successful, check the output for your load balancer URL:

terraform output load_balancer_url

You should see a URL, e.g., terraform-lb-12345678.us-east-1.elb.amazonaws.com. Open this URL in your browser to see the “OK” response from the application load balancer.

Step 9: Clean Up Resources (Optional)

To remove the deployed infrastructure:

terraform destroy -auto-approve

Step 10: Bonus – Creating a Key Pair (If Needed)

If you don’t have a key pair yet:

aws ec2 create-key-pair --key-name my-aws-key --query 'KeyMaterial' --output text > my-aws-key.pem
chmod 400 my-aws-key.pem

Summary of the Extended Terraform Tutorial

This tutorial includes the creation of:

VPC and Subnet for networking.
Security Group for access control.
Auto Scaling Group with dynamic scaling based on the instance count.
Load Balancer for distributing traffic to the instances.
Target Group and Listener to attach the instances to the load balancer.
